Do Arcade Machines Use a Lot of Electricity?

A modern LCD arcade machine draws about 25–45 watts and a CRT cabinet about 100. Here is what that costs at home and in a venue, hour by hour.

Updated Nov 12, 202612 min readBy Reviewed by
Do Arcade Machines Use a Lot of Electricity?

Highlights

  • A modern LCD arcade machine draws roughly 25–45 watts; a 1980s–90s CRT cabinet roughly 90–240, typically about 100
  • At home, two hours of play a day costs under 50 cents a month on an LCD machine and about a dollar on a CRT cabinet
  • Switched on 10–12 hours a day in a bar or arcade, a CRT cabinet costs about $5–15 a month and an LCD machine a few dollars
  • Count the hours a machine is switched on, not the hours played: classic cabinets have no sleep mode

Arcade machines use less electricity than most owners expect: for a home machine it is the smallest cost of owning it, about a dollar a month or less. What moves the bill is how many hours the machine stays switched on and whether it has an old CRT monitor, not how often you play.

Below: what each type of machine draws, what it costs to run at home and in a bar where it stays on all day, what a pinball machine adds, why old cabinets are hungrier, and how to measure your own machine.

How Many Watts Does an Arcade Machine Use?

Power draw depends mostly on the screen. A flat LCD panel and a small computer board need little power. A picture tube, its high-voltage circuits and an old linear power supply need several times more. The figures below are what machines draw in real use, not the rating printed on the back of the cabinet.

Machine typeDraw in real useWhy
Modern LCD or Raspberry Pi home cabinetAbout 25–45 WA 22-inch monitor and a small computer board
Arcade1Up full-size replicaNever more than 36 WIts 12-volt power adapter sets the limit
1980s–90s CRT uprightAbout 90–240 W, typically 100 WPicture tube and linear power supply
Pinball machineAbout 1–2 amps; fused at 8 ampsLamps, boards and coils that fire in bursts

The CRT range is wide because cabinets differ. Owners who have put a meter on classic uprights mostly find them drawing about an amp. Dual-monitor games and some badly designed power supplies pull more than 2 amps, and those set the top of the range. Most cabinets sit near the bottom, which is why about 100 watts is a fair figure for one original upright.

Range chart: an LCD cabinet draws about 25–45 W, a CRT upright about 90–240 WWatts in real use050100150200250Modern LCD cabinetabout 25–45 WArcade1Up replicaup to 36 W, the adapter's limitOriginal CRT uprightabout 90–240 W, typically 100
Typical draw while the machine is on, not the rating on the label. A pinball machine draws about 1 to 2 amps and is covered in its own section below.

The Arcade1Up figure works differently. These replicas run from an external 12-volt, 3-amp adapter, and an adapter cannot deliver more than its rating, so 36 watts is a ceiling rather than a typical reading.

Two kinds of home machine fall outside the LCD range:

  • A cabinet built around a desktop PC with a graphics card. It behaves like a gaming PC, and under load it can draw as much as a CRT cabinet or more.
  • A machine with a very large screen. A bigger panel needs a bigger backlight, so it draws more.

If your machine is either of these, measure it rather than relying on the table.

The JVL ECHO HD3 is a bartop with a 22-inch LCD touchscreen and a solid-state board, so it belongs with the modern LCD machines at the top of the table, not with the CRT cabinets.

How Much Does It Cost to Run an Arcade Machine?

Two things set the bill: how many hours a day the machine is switched on, and what you pay per kWh. The table below uses the US average residential price. A CRT cabinet that costs about a dollar a month at two hours a day costs about $13 if it is never switched off.

Hours switched on per dayLCD machine, 25–45 WCRT cabinet, 100 WHungry CRT cabinet, 240 W
2 hours (typical home)Under 50 centsAbout $1About $2.50
4 hours (heavy home use)Under $1About $2About $5
10–12 hours (bar or arcade)About $1.50–3About $6About $13–16
24 hours (never switched off)About $3–6About $13About $30

Monthly cost for one machine at the US average residential electricity price.

Bar chart: monthly cost of an LCD and a CRT machine at 2, 4, 12 and 24 hours a dayMonthly cost of one machine, by hours switched on per day0$5$10under 50¢about $12 hourshomeunder $1about $24 hoursheavy homeabout $3about $610–12 hoursbar or arcadeabout $6about $1324 hoursnever offLCD machineCRT cabinet
At the US average residential electricity price, with the LCD machine at the top of its range and a typical CRT cabinet. The hours a machine is switched on move the bill more than the type of machine does.

Your own rate matters as much as your machine. State averages run from nearly a third below the national figure to more than double it in Hawaii, so check the price per kWh on your bill and scale the table to match. Even in Hawaii, a CRT cabinet played two hours a day costs under $3 a month.

For scale, a refrigerator runs all day and uses several times more electricity in a month than a CRT cabinet played every evening. An arcade machine only becomes noticeable on the bill when it is left on around the clock, and even then it is a small line.

If running costs are what is holding you back from a home machine, our guide to whether home arcade machines are worth getting covers the costs that matter more: the purchase, repairs and space.

Count the Hours It Is Switched On, Not the Hours Played

A machine is often switched on far longer than anyone plays it, and the bill follows the switch. An original 1980s video cabinet has no sleep mode. Once it is on, it runs its attract loop with the monitor, the boards and the marquee lamp all lit, and it keeps drawing about what it draws in a game until someone turns it off.

A pinball machine can draw more when nobody is playing. Owners who metered their machines found:

  • a 1970s Gottlieb electromechanical game drew a little over an amp in play and more in game-over mode, when every player's score is lit;
  • a late-1970s Williams drew about 2 amps in attract mode and less during a game, because fewer lamps are lit in play;
  • a Bally from the same years drew about the same either way.

Modern home machines vary. Some dim or switch off the screen when nobody touches them, others stay fully on, and the manual rarely says how much they draw while idle. A plug-in meter, described below, settles it for your machine.

Either way, the rule is simple. If the machine sits on a switched power strip or a smart plug and goes off when the room is empty, the two-hour and four-hour rows of the table apply. If it stays on from morning to midnight, use the 10–12-hour row, even at home.

How Much Electricity Does a Pinball Machine Use?

More than an LCD video machine, and usually less than people fear. The readings above, 1 to 2 amps, put a 1970s pinball machine in the same band as a classic CRT upright. Modern pinball machines with LED lighting and a screen for the score use less on lamps, but their coils still pull short, heavy bursts of current when they fire. They also keep their lights and display running in attract mode, so the rule about hours switched on applies to them too.

Those bursts are why a pinball machine is fused at 8 amps even though it averages far less. Use the fuse rating when you plan circuits and the measured draw when you think about the bill. Our home arcade room planning guide shows how a pinball machine fits on a household circuit alongside video cabinets.

Why Does a CRT Cabinet Draw More Power?

A CRT arcade monitor is a vacuum tube. To light the screen it heats a filament, fires electrons at the glass with tens of thousands of volts and sweeps the beam across the tube with magnetic coils, line by line, many times a second. All of that runs whether the picture is bright or dark.

The rest of the cabinet adds to the load:

  • Linear power supplies with heavy transformers turn much of their input into heat before the boards see any of it.
  • Game boards of the period carry dozens of separate chips rather than one efficient processor.
  • The marquee is usually lit by a fluorescent tube with its own ballast.
  • Dual-monitor games run two tubes at once.

A modern machine replaces each of those parts with something far more efficient: an LCD panel with an LED backlight, a switch-mode power supply and a single computer board.

Circuit board, heat sinks and wiring inside an older arcade cabinet
Inside an older cabinet: heat sinks and transformers turn much of the power into heat. Photo: Adrian Purser, CC BY-SA 2.0, Wikimedia Commons.

Many original cabinets have had their tube swapped for an LCD panel when the monitor failed. That cuts the draw, but not to modern levels if the old power supply, game board and fluorescent marquee stay in place. Owners who convert a cabinet often replace the power supply at the same time, and the only way to know what a converted cabinet draws is to measure it.

Every watt a cabinet draws ends up as heat in the room. One CRT cabinet warms a room about as much as an old 100-watt light bulb, and six of them in a small basement are noticeable on a summer evening. That heat, more than the bill, is the real cost of a row of original cabinets at home. If you are weighing an original cabinet against a modern one, what arcade machines cost, then and now covers the purchase side.

How to Measure Your Own Machine

A plug-in electricity meter in a wall socket, with a power cord plugged into it
A plug-in meter sits between the socket and the machine's cord (European socket shown). Photo: Zátonyi Sándor (ifj.), CC BY-SA 3.0, Wikimedia Commons.

Published figures are averages. An inexpensive plug-in watt meter tells you what your own machine draws. It sits between the wall socket and the power cord and shows watts, amps and the kilowatt-hours used since you plugged it in. The common Kill A Watt model handles up to 15 amps, which covers any home arcade machine.

To get a useful reading:

  • Plug the meter into the wall and the machine into the meter, then switch the machine on.
  • Read the watts while it sits in attract mode, then again during a game.
  • Switch the meter to its kilowatt-hour count and leave it in place for a normal week.
  • Multiply the week's kilowatt-hours by about four for a month, then by the price on your bill.

The week-long count is the most honest figure, because it includes the hours the machine spends switched on but idle. If you would rather not buy a meter, many public libraries and some utilities lend them out.

If several machines share one power strip, plug the strip into the meter and you see the whole row at once. It is also the quickest check on a circuit: if the row draws close to 12 amps with everything on, that circuit is full.

The label on the back of the cabinet is a poor guide. It gives the most the machine is built to handle, and owners regularly find cabinets labelled 5 amps drawing well under that in real use. Use the label to plan circuits, not to estimate the bill.

“Assume the average is about 100 watts, not much more than a 19" TV.”

A collector who measured their classic cabinets with a plug-in meter, on the KLOV forums, 2007

How Many Arcade Machines Can Share a Circuit?

A household circuit is planned to 80 percent of its breaker rating, about 12 amps on a 15-amp circuit. An original upright draws about 1 to 3 amps, so a 15-amp circuit holds a handful of them, while a pinball machine planned at 8 amps leaves room for only two more uprights. Modern LCD machines draw a fraction of an amp and barely register. Circuit-by-circuit planning, with wiring and when to call an electrician, is in our home arcade room planning guide.

Is Electricity a Big Cost for a Bar or Arcade?

No, but it is a real line item. A CRT cabinet switched on for 10 to 12 hours a day costs about $5 to $15 a month in electricity, and a modern LCD machine a few dollars. Operators who have run the numbers for classic cabinets on collector forums land in the same range.

Set against what a machine takes in, that is small. Our model of one arcade machine in a bar budgets $10 a month for electricity, inside about $55 a month of total running costs. Maintenance is the bigger and less predictable item.

Two things change the picture for a whole venue. Thirty or forty cabinets add their heat to the room, so in summer some of the cost moves to the air conditioning. And commercial electricity rates and demand charges are not the same as residential ones, so a venue should work from its own tariff rather than the residential average used here.

Some operators put machines on timers or motion sensors so they switch off in quiet hours. The saving per machine is a few dollars a month at most, so for most venues it matters less than having every machine lit and ready when a customer walks in.

What This Means When You Choose a Machine

For a home machine, electricity should not decide anything. At normal hours, the gap between the cheapest and the hungriest machine in the table is a few dollars a month. Three questions matter more:

  • Will it be switched off when nobody is playing? If not, budget from the 24-hour row.
  • Is it a CRT cabinet in a small room? Then plan for the heat and check the circuit.
  • Is there a pinball machine in the mix? Then plan its circuit at 8 amps.

For a venue, compare a month of electricity, at most $5 to $15 even for a hungry original, with what the machine takes in a week. If a week's takings do not cover a month of electricity with plenty to spare, the problem is the location, not the machine.

Frequently asked questions

How many watts does an arcade machine use?

A modern LCD arcade machine draws roughly 25 to 45 watts. An original 1980s or 90s CRT cabinet draws roughly 90 to 240 watts, typically about 100, mostly because of the picture tube and its old power supply.

How much does it cost to run an arcade machine each month?

At home, two hours a day: under 50 cents for LCD and about a dollar for a CRT. In a venue, 10 to 12 hours a day: about $5 to $15 for a CRT, a few dollars for LCD.

How much electricity does a pinball machine use?

Owners who metered 1970s machines found them drawing 1 to 2 amps, close to a classic CRT arcade cabinet. A pinball machine is fused at 8 amps because of its coils, so plan circuits around that figure.

Can you leave an arcade machine on all the time?

You can, but you pay for every hour it is on, played or not. A classic cabinet has no sleep mode, and a CRT cabinet left on around the clock costs about $13 a month at the US average price.

Do old arcade machines use more electricity than new ones?

Yes, several times more. A CRT cabinet typically draws about 100 watts against roughly 25 to 45 for a modern LCD machine, because the tube, the old power supply and the fluorescent marquee all turn power into heat.
